293 HEIDENHAIN TNC 410
1
5
.3
T
e
c
hnical
Inf
o
rmation
Programmable functions
Contour elements
■ Straight line
■ Chamfer
■ Circular arc
■ Circle center
■ Circle radius
■ Tangentially connecting arc
■ Corner rounding
■ Straight lines and circular arcs for contour approach and departure
FK free contour programming
For all contour elements not dimensioned for conventional NC
programming
Program jumps
■ Subprograms
■ Program section repeats
■ Main program as subprogram
Fixed cycles
■ Drilling cycles for drilling, pecking, reaming, boring, tapping with a
floating tap holder, rigid tapping
■ Milling and finishing rectangular and circular pockets
■ Cycles for milling linear and circular slots
■ Regular linear and circular point patterns
■ Irregular linear and circular hole patterns
■ Cycles for multipass-milling of flat and twisted surfaces
■ Milling pockets and islands from a list of subcontour elements
Coordinate transformations
■ Datum shift
■ Mirroring
■ Rotation
■ Scaling factor
3-D touch probe applications
■ Touch probe functions for setting datums and for automatic
workpiece measurement
■ Digitizing 3-D surfaces with triggering touch probe (optional)
■ Automatic workpiece measurement with TT 120
