To change the detail magnification:
The soft keys are listed in the table above.
ú Interrupt the graphic simulation, if necessary.
ú Use a soft key to select the workpiece surface
ú To reduce or magnify the blank form, press and hold
the minus or plus soft key, respectively.
ú To select the isolated detail, press the TRANSFER soft
key.
ú Restart the test run by pressing the START soft key
(RESET + START returns the workpiece blank to its
original state).
Repeating graphic simulation
A part program can be graphically simulated as often as desired,
either with the complete workpiece or with a detail of it.
Function Soft key
Restore workpiece blank to the detail
magnification in which it was last shown
Reset detail magnification so that the machined
workpiece or workpiece blank is displayed as it
was programmed with BLK FORM
With the WINDOW BLK FORM soft key, you return the
displayed workpiece blank to its originally programmed
dimensions, even after isolating a detail TRANSFER
TRANSFER DETAIL).
