Basketball Operations 69
Dimming Menu
The Dimming Menu allows the user to change the brightness of the scoreboard.
Display Action
NN = current level
NONE = bright <0>
90% = <1>
80% = <2>
70% = <3>
60% = <4>
50% = <5>
40% = <6>
30% = <7>
20% = <8>
10% = <9>
Press <0> through <9> or use the arrow keys to select the
intensity for the digits on the scoreboard.
Press to resume the game in progress using the
current data, and exit the Menu.
Press the down arrow key to scroll to the next selection.
Note: The incremental dim levels pertain only to outdoor
LED products. Indoor LED and incandescent products
only support one level of dimming at 50%.
Home Roster, Guest Roster
Home Roster and Guest Roster are entered in the same way. Home Roster is used as an
example.
Display Action
Press or the right or left arrow key to select the
Home or Guest Roster submenu and show the first prompt on
the LCD.
Press to resume the game in progress using the
current data and exit the Menu.
Press the down arrow key to scroll to the next selection.
The TEAM NAME (LL-2441) insert must be used to enter
the Team Name Message Center (TNMC) settings.
The TNMC is updated after each selection is completed.
Use the COLUMNS, ROWS and STROKE keys to select the
WIDTH, HEIGHT and FONT of the TNMC. Refer to Section
2.8 for more information about team name entry.
Enter up to fifteen (15) characters for the team name and
press .
Insert the BASKETBALL (LL-2433) insert to continue.
MENU- DI MMI NG
LEVEL (0-9): NN%
MENU- ROSTER
SELECT HOME
HOME- TEAM NAME
_OME *
