50 Pitch & Speed Operations
Angle Offset Coefficient
Approximately every one hundredth from the coefficient
will increase the speed by one mph.
Example: 0.9848 = 95mph
0.9748 = 96mph
For more exact calculations, refer to Drawing A-243741
in Appendix A.
10° 0.9848
15° 0.9659
20° 0.9397
25° 0.9063
30° 0.866
Select Speed Range
Display Action
NN = current setting
This setting allows the user to select a speed range that will
be accepted from the radar gun. Type in the minimum speed
and then press . Type in the maximum speed and
the press . The default minimum speed setting is 0
MPH and the default maximum is 105 MPH.
Speed Indicator
Display Action
NN= current setting
This setting allows the user to select the speed at which the
three speed indicators should light. Speeds below the 1st
setting will light the 1st indicator.
Speeds equal to or greater than the 1st and less than the 2nd
setting will light the second indicator. Speeds greater than this
will logout the 3rd indicator. Enter the desired values and
press after each is entered.
Auto Frame #
Display Action
This option sets the default frame number that is sent with a
pitch when in Auto mode. Use the keypad to enter a value
from 0-20 and press .
SELECT RANGE
SPEED: >NN MPH
SPEED I NDI CATOR
1ST NN* MPH
SPEED I NDI CATOR
2ND NN* MPH
AUTO FRAME #
01
