12 Basic Operation
Typically, all multiple controller systems will use BCAST 1, CHAN 1 for the first controller
in Broadcast Group 1 and BCAST 2, CHAN 1 for the first controller in Broadcast Group 2.
All other consoles in a group are added sequentially.
Display Action
The LCD will toggle between
these 2 screens.
The LCD shows the current radio settings along with a prompt
to accept or modify these values.
If the radio settings are correct press .
If these values are incorrect press , and the LCD at
bottom left is shown, allowing edit of the channel or broadcast
group setting.
Use the number keys to enter the desired broadcast group
and press to accept. The asterisk will move to the
channel setting.
Edit the channel number to the desired value and press
to accept.
Broadcast
Group Channel
Setting
Control Scoreboards
0 0 All Scoreboards
1
0 All in BCAST Group 1
1-8
Set to corresponding BCAST 1
Channel
8*
0 All in BCAST Group 8
1-8
Set to corresponding BCAST 8
Channel
* Gen V radio receivers have only 4 groups; also, on
broadcast groups 2 and 4, only channels 1-4 may be used.
ENTER TO ACCEPT
CLEAR TO MODI FY
BCAST GROUP 1*
RADI O CHAN 01
RADI O SETTI NGS
BCAST X CHAN YY
