258 Water Polo Operations
Setting Result
N = current setting
The switch closes when the main clock is stopped and opens
when the main clock is running. External devices are disabled
when the main clock is running.
N = current setting
The switch closes when the main horn sounds. This could be
when Auto Horn is enabled and the main clock reaches zero
or when is pressed.
Default Settings
Print this page if necessary, and record any custom settings for this installation:
Setting Default Custom 1 Custom 2 Custom 3
Tenth of a Second Yes
Period Length 15:00
Break Length 10:00
Overtime Length 5:00
Shot Reset 1 0:35
Sync Shot with Main Yes
Auto Blank Yes
Penalty Time 0:20
Full Time Outs 1
Full Time Out 1:00
Time Out Show on Main No
Horn Ind./Comb. INDEPENDENT
Switch Output 1-Clock = 0
SWI TCH OUTPUT=N
2-CLOCK =STOP?
SWI TCH OUTPUT=N
3-MAI N HORN?
