Basketball Operations 57
Section 7: Basketball Operations
Sport Insert: LL-2433
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A. The Quick Reference is located in Appendix D.
Reference Drawings:
Insert, Basketball, LL-2433 ................................................................................. Drawing A-120121
Block Diagram: AS5000 BB- VB and WR #1 ...................................................... Drawing A-124686
Block Diagram: AS5000 BB- VB and WR #3 ...................................................... Drawing A-124688
Insert; LL-2442 A/S 5000, Team Name .............................................................. Drawing A-125290
Block Diagram- A/S 3000 or 5000 BB- VB and WR #2 ....................................... Drawing A-125415
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
Use the label sheet provided with the console (Daktronics part # LL-2458) to attach the correct code
number label to the sport insert in the designated location. Write the code number in the space below.
If viewing a digital copy of this manual, print this page and fill in the code number.
Write the correct code number here:
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
7.1 Basketball Keys
Set Shot Time
Display Action
MM:SS = minutes, seconds
Press > to display the current shot clock
time length.
To accept the current shot clock time length press .
To decline the selection of the current shot clock time length
press .
Use the keypad to enter the new time in minutes and seconds
and press .
Press twice to clear changes and return to the
game.
SHOT CLOCK-EDI T
CURR MM:SS*
