282 Australian Rules Football/Cricket Operations
Switch Output
The All Sport ® 5000 console has a switch that can be used to run a number of different
devices. The switch can be configured to operate under different settings. The default setting
is 1-CLOCK= 0. To display the desired switch setting:
1. Press the number (0, 1, 2, 3) key as a shortcut or use the left and right arrow keys to
scroll to the desired setting.
2. Press to select the new setting.
3. Press or the down arrow key to leave the switch setting and display the next
prompt.
The possible settings for the switch output are as follows:
Setting Result
N = current setting
The switch remains open at all times and any external devices
are disabled.
N = current setting
In count down mode, the switch closes when the main clock
reaches zero and remains closed until a nonzero value is
entered.
In count up mode, the switch closes when the main clock
reaches the proper period, break, or overtime length and
opens when any other value is entered.
N = current setting
The switch closes when the main clock is stopped and opens
when the main clock is running. External devices are disabled
when the main clock is running.
N = current setting
The switch closes when the main horn sounds. This could be
when Auto Horn is enabled and the main clock reaches zero
or when is pressed.
Default Settings
Print this page if necessary, and record any custom settings for this installation:
Setting Default Custom 1 Custom 2 Custom 3
Tenth of a Second No
Period Length 12:00
Break Length 20:00
Overtime Length 5:00
Switch Output 1-Clock = 0
SWI TCH OUTPUT=N
0-DI SABLED?
SWI TCH OUTPUT=N
1-CLOCK =0?
SWI TCH OUTPUT=N
2-CLOCK =STOP?
SWI TCH OUTPUT=N
3-MAI N HORN?
