Karate Operations 195
Section 16: Karate Operations
Sport Inserts: 0G-96890 Red/White Code 282
0G-98374 White/Red Code 285
The Sport Insert drawing is located in Appendix B. The Block Diagram drawings are located in
Appendix A.
Reference Drawings:
Insert, Karate Code 282 ........................................................................................ Drawing A-96890
Custom Insert, Karate Code 285 ........................................................................... Drawing A-98374
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
16.1 Karate Keys
W (Wazaari)
Display Action
N = current setting
Press to increment and to decrement the
Wazaari value for the selected competitor.
H (Hansoku)
Display Action
N = current setting
Press to increment and to decrement the
Hansoku for the selected opponent.
M (Mubobi)
Display Action
N = current setting
Press to increment and to decrement the
Mubobi value for the selected competitor
WHI TE W +1
N
WHI TE H +1
N
WHI TE M +1
N
