Judo Operations 211
Section 18: Judo Operations
Sport Insert: 0G-96891 Blue/White Code 281
0G-98376 White/Blue Code 284
The Sport Insert drawing is located in Appendix B. The Block Diagram drawings are located in
Appendix A.
Reference Drawings:
Insert, Judo Code 281 ........................................................................................... Drawing A-96891
Custom Insert, Judo Code 284 ............................................................................. Drawing A-98376
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
18.1 Judo Competitor Status
Display Action
MM:SS = minutes, seconds
W = waza ari score position
Y = yuko score position
K = koka score position
N = penalty character position
+ + = medical exam positions
The bottom line of the LCD will either display the Osaekomi
time, the medical time, or the competitor status during the
operation of the console in this mode.
When competitor status is displayed, it will show from left to
right the one digit score (waza ari, yuko, koka), one character
for penalties (K, C, S) and two possible medical exam
indicators (+, +).
This information is repeated for the other competitor. The data
will be displayed on the LCD from left to right according to the
code entered into the All Sport 5000 console: Blue-White
(Code 281) or White-Blue (Code 284).
TI ME MM:SS }
WYK N++ WYK N++
