232 Strikeout Count Operations
Display Control Keys
The display control keys will send the selected frame command through the RTD port.
Pressing these keys will initiate the display of that frame on the Venus
® matrix control
system. The frames will be sent as Enhanced RTD Fields and have the following protocols:
19200 baud, 8 data bits, and no parity. The frame number for each of the keys is listed below:
------------------------------ Frame 1
--------------------------------- Frame 2
--------------------------------- Frame 3
--------------------------------- Frame 4
--------------------------------- Frame 5
--------------------------------- Frame 6
--------------------------------- Frame 7
--------------------------------- Frame 8
--------------------------------- Frame 9
--------------------------------- Frame 10
-------------------------------- Frame 11
-------------------------------- Frame 12
-------------------------------- Frame 13
-------------------------------- Frame 14
-------------------------------- Frame 15
-------------------------------- Frame 16
-------------------------------- Frame 17
-------------------------------- Frame 18
-------------------------------- Frame 19
-------------------------------- Frame 20
--------------------- Frame 21 + the strikeout count
(example: 0 strikeouts = Frame 21)
1 strikeout = Frame 22)
2 strikeouts = Frame 23)
20.2 Menu
The
New Game
Display Action
Press to clear all of the program data for the last game
played or the game in progress and begin running the
selected sport.
Press to resume the game in progress using the
current data and exit the Menu.
Press the down arrow key to scroll to the next selection.
MENU- MAI N
NEW GAME?
