Baseball Operations 29
Section 4: Baseball Operations
Sport Insert: LL-2438
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A. The Quick Reference is located in Appendix D.
Reference Drawings:
Insert; LL-2438 A/S 5000, Baseball ..................................................................... Drawing A-125061
Insert; LL-2441 A/S 5000, Team Name .............................................................. Drawing A-125290
Block Diagrams, A/S 3000 or 5000 Outdoor Sports............................................ Drawing A-124690
Refer to the information in Section 2 to start up the console and how to use the sport insert.
If an insert is lost or damaged, a copy of the insert drawings can be used until a replacement arrives.
Use the label sheet provided with the console (Daktronics part # LL-2458) to attach the correct code
number label to the sport insert in the designated location. Write the code number in the space below.
If viewing a digital copy of this manual, print this page and fill in the code number.
Write the correct code number here:
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
4.1 Baseball Keys
Note: If game stats are being received from the Daktronics Scoring-Timing Interface
(DSTI), the keys on the console will be disabled. The LCD displays the messages shown
below when these keys are pressed. Refer to ED-13009 for more information about DSTI.
Display Action
The key disabled message will display for one second and
then the message will display and wait for a
or key. If the key is pressed, the stats
data will be saved in the console, and the console will
STATS> mode until another stats packet is received. This will
allow the operator to enter stats from the console if the
connection to DSTI is lost.
STATS RECEI VED
KEY DI SABLED
EXI T STATS MODE
Y/N?
