270 Rugby Operations
Display Action
MM:SS = minutes, seconds
Enter the correct amount of time per period in minutes and
seconds on the number pad and press .
For example, 20:00 per half or 8:00 per quarter
Note: Pressing to select the period time as the
main clock setting will increment the current period
number if the clock value was previously zero.
MM:SS = minutes, seconds
Set the amount of time between periods.
Enter the correct amount of time for break length in minutes
and seconds on the number pad and press .
For example, 1:00
MM:SS = minutes, seconds
Set the amount of time for the overtime periods.
Enter the correct amount of time for overtime periods in
minutes and seconds on the number pad and press
.
For example, 5:00
Switch Output
The All Sport ® 5000 console has a switch that can be used to run a number of different
devices. The switch can be configured to operate under different settings. The default setting
is 1-CLOCK= 0. To display the desired switch setting:
1. Press the number (0, 1, 2, 3) key as a shortcut or use the left and right arrow keys to
scroll to the desired setting.
2. Press to select the new setting.
3. Press or the down arrow key to leave the switch setting and display the next
prompt.
The possible settings for the switch output are as follows:
Setting Result
N = current setting
The switch remains open at all times and any external devices
are disabled.
MAI N CLOCK-TI ME
PERI OD MM:SS*
MAI N CLOCK-TI ME
BREAK MM:SS*
MAI N CLOCK-TI ME
OVERTI ME MM:SS*
SWI TCH OUTPUT=N
0-DI SABLED?
