18 Basic Operation
Count Up/Down
Display Action
After the main clock has been stopped, the direction of the
clock can be set.
Press <1> or <2> to select UP or DOWN (default).
Note: The current direction of the main clock is shown on
the top line of the LCD.
The function is disabled while the clock
is already running.
Auto Horn
Display Action
Press <1> or <2> to select ON (default) or OFF. The amber
LED on the key is on when the Auto Horn feature is
enabled. The LED is off when the Auto Horn feature is
disabled and the horn is in Manual mode.
Manual Horn
Press to sound the main horn. The horn sounds as long as the key is pressed.
2.6 Remote Start/Stop Controls
The All Sport ® 5000 console lets additional operators control timing functions remotely using
the Main Clock Start/Stop switch and the Shot Clock Start/Stop switch.
Figure 9: Remote Start/Stop Switches
MAI N CLOCK- DOWN
1-UP 2-DOWN
AUTO HORN- ON
1-ON, 2-OFF
