100 Football Operations
Setting Result
N = current setting
In count down mode, the switch closes when the main clock
reaches zero and remains closed until a nonzero value is
entered.
In count up mode, the switch closes when the main clock
reaches the proper period, break, or overtime length and
opens when any other value is entered.
N = current setting
The switch closes when the main clock is stopped and opens
when the main clock is running. External devices are disabled
when the main clock is running.
N = current setting
The switch closes when the main horn sounds. This could be
when Auto Horn is enabled and the main clock reaches zero
or when is pressed.
Default Settings
Print this page if necessary, and record any custom settings for this installation:
Setting Default Custom 1 Custom 2 Custom 3
Tenth of a Second No
Period Length 12:00
Break Length 20:00
Overtime Length 5:00
Play Clock Reset 1 0:25
Play Clock Reset 2 0:40
Play Clock Reset On Stop No
Full Time Outs 3
Full Time Out 1:00
Time Out Warning 0:00
Partial Time Outs 0
Partial Time Out 0:00
Show on Main No
Center of Field 50
Auto Calculate No
First Down Yards 10
Number of Downs 4
Select Captions 1-ON
Score by Quarter No
Switch Output 1-Clock = 0
SWI TCH OUTPUT=N
1-CLOCK =0?
SWI TCH OUTPUT=N
2-CLOCK =STOP?
SWI TCH OUTPUT=N
3-MAI N HORN?
