Pitch & Speed Operations 51
Display Mode
Display Action
This setting determines when the pitch information received
will be updated to fixed digit scoreboards and RTD. In Auto
mode, the scoreboard/RTD is updated as soon as speed
information is received from the radar gun.
In Manual mode the console waits for one of the pitch keys to
be pressed before updating with the new pitch speed.
Note: In Auto mode the pitch keys are not used.
Default Settings
Print this page if necessary, and record any custom settings for this installation:
Setting Default Custom 1 Custom 2 Custom 3
Cycle Time 00:05
Blank Time 00:20
Radar Gun Type JUGS
Speed Adjust Coefficient 0
Min Speed 0
Max Speed 105
Display Mode AUTO
RTD Item Numbers
The Pitch and Speed function uses RTD item numbers to display pitch information. Items 23-
25 will display either MPH or KPH depending on cycle and display settings.
Item # Data
1 MPH x100
2 MPH x10
3 MPH x1
4-19 Pitch type text – 16 characters
20 KPH x100
21 KPH x10
22 KPH x1
23 MPH/KPH x100
24 MPH/KPH x10
25 MPH/KPH x1
26 MPH indicator
27 KPH indicator
28 Home Ball count x100
29 Home Ball count x10
30 Home Ball count x1
31 Home Strike count x100
DI SPLAY MODE
*AUTO[]MANUAL
