Volleyball Operations 169
Display Action
Press to display the time out time on the LCD and the
main clock digits of the scoreboard while the time out clock is
active.
Press to display the time out time on the LCD only.
Press to enable FIBA mode (international rules).
This will display number of time outs taken on the scoreboard.
At the beginning of a new game, time outs will start at 0 and
increment as they are taken, up to the max configured value.
Press to show time outs remaining on the scoreboard.
Team Stats
Display Action
This feature must be enabled for statistics displays.
Press to allow entry of a player number after the home
or guest team aces, kills, blocks or digs are incremented or
decremented. Press to prevent entry of a player number.
User Def 1 & User Def 2
User Def 1 and User Def 2 are used to define which statistics (aces, kills, blocks or digs) are
displayed on the scoreboard. Only two of the four statistics can be selected to display on the
statistics displays for the individual players in the game.
 User Def 1 displays the statistics in the Team Score digits.
 User Def 2 displays the statistics in the Player/Foul digits.
User Def 1 and User Def 2 are entered in the same way. User Def 1 is used as an example.
Display Action
N = current setting

Press <1> or use the left and right arrow keys to
scroll to ACES.

Press <2> or use the left and right arrow keys to
scroll to KILLS.

Press <3> or use the left and right arrow keys to
scroll to BLOCKS.

Press <4> or use the left and right arrow keys to
scroll to DIGS.
Press <YES> to display the selected stat on the scoreboard.
Press <NO> to decline the selection and return to the game.
Press the down arrow key to scroll to the next selection.
TI ME OUTS-MODE
SHOW ON MAI N? N
TEAM STATS-MODE
UPDATE PLAYER? Y
USER DEF 1=N
1-ACES
USER DEF 1=N
2-KI LLS
USER DEF 1=N
3-BLOCKS
USER DEF 1=N
4-DI GS
FI BA MODE
Y/N? N
