Strikeout Count Operations 231
Section 20: Strikeout Count Operations
Sport Insert: 0G-163409 Strikeout Count Code: 5099
The Sport Insert drawings are located in Appendix B. The Block Diagram drawings are located in
Appendix A.
Reference Drawings:
Insert; Strike Outs ............................................................................................... Drawing A-163409
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
20.1 Strikeout Keys
Season Strikeouts
Display Action
NNNN = current setting
Press •> to set the value for the
season total strikeouts. Enter the correct value using the
number pad and then press .
Game Strikeouts
Display Action
NNN = current setting
Press •> to set the value for the
current game strikeouts. Enter the correct value using the
number pad and then press .
Strikeouts +1, -1
Display Action
NNN = current setting
Press to increment and
-1> to decrement the strikeout count for the game and season
by one.
The selected frame for the game strikeout count is sent
through the RTD port each time the key is pressed.
TOTAL: EDI T
NNNN*
CUR VALUE: EDI T
NNN*
CUR VALUE: +1
NNN
