170 Volleyball Operations
Select Captions
Display Action
This menu option allows for the controlled backlit captions to
be turned ON/OFF.
Press the <1> key to select ON and OFF for captions
controlled by control #1.
Press the <2> key to select ON and OFF for captions
controlled by control #2.
Switch Output
The All Sport ® 5000 console has a switch that can be used to run a number of different
devices. The switch can be configured to operate under different settings. The default setting
is 1-CLOCK= 0.
To display the desired switch setting:
1. Press the number (0, 1, 2, 3) key as a shortcut or use the left and right arrow keys to
scroll to the desired setting.
2. Press to select the new setting.
3. Press or the down arrow key to leave the switch setting and display the next
prompt.
The possible settings for the switch output are as follows:
Setting Result
N = current setting
The switch remains open at all times and any external devices
are disabled.
N = current setting
In count down mode, the switch closes when the main clock
reaches zero and remains closed until a nonzero value is
entered.
In count up mode, the switch closes when the main clock
reaches the proper period, break, or overtime length and
opens when any other value is entered.
SELECT CAPTI ONS
ON 1[- -] 2 OFF
SWI TCH OUTPUT=N
0-DI SABLED?
SWI TCH OUTPUT=N
1-CLOCK =0?
