6 Basic Operation
2.2 Sport Inserts
Sport inserts allow a single console to control multiple sports. Select the proper insert from
the chart below and slide it into the insert opening on the left side of the console until it stops.
To remove a sport insert, pull on the tab that extends from the left side of the console.
If an insert is lost or damaged, a printed copy of the insert drawing, located in Appendix B,
may be used until a replacement can be ordered. Print this page (if not available) and write
the code number in the following table for all applicable sports.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number
of a scoreboard is unknown, refer to the documentation provided with the scoreboard.
Sport Insert Number Number Code
Baseball LL-2438
Basketball LL-2433
Boxing 0G-96892
Cricket 0G-319507
Cricket/Football 0G-315384
Event Counter 0G-58047
Football LL-2437
Hockey/Lacrosse/Handball LL-2436
Judo 0G-96891, 0G-98376
Karate 0G-96890, 0G-98374
Lacrosse 0G-1084219
Pitch and Speed LL-2482
Rugby 0G-712154
Segment Timer LL-2475 Not applicable
Soccer LL-2440
Strikeout 0G-163409
Tae kwon do 0G-96889, 0G-98375
Tennis LL-2483
Track LL-2439
Team Name (TNMC) LL-2441
Volleyball LL-2434
Water Polo 0G-178439
Wrestling LL-2435
Sport Insert Operation Concepts
A sport insert identifies the keys required for normal operation of a specific sport. In most
cases, pressing a key immediately changes the scoreboard. Keys that require entry of
additional information are marked by a dot. This additional information is usually a number
followed by the key.
Keys with arrows activate an indicator (possession, bonus, etc.) on the scoreboard.
The direction of the arrow selects the appropriate team (home or guest).
