Boxing Operations 223
Section 19: Boxing Operations
Sport Insert: 0G-96892 Boxing Code: 0291
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A.
Reference Drawings:
Insert, Boxing Code 291 ........................................................................................ Drawing A-96892
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
19.1 Boxing Keys
Set Round Time/Set Rest Time
and have similar functions and are described
by the table below. In the LCD below, is used as an example.
Display Action
MM:SS = minutes, seconds
Press •> or to set
the value for the respective time. Enter the correct value
using the number pad and then press .
Press twice to cancel and resume the match.
Maximum Round Number
Display Action
NN = current setting
< MAXIMUM ROUND NUMBER •> sets the value for the
maximum number of rounds in the match. Enter the correct
value using the number pad and then press .
Press twice to cancel and resume the match.
ROUND TI ME
TI ME MM:SS *
MAX ROUND: EDI T
NN*
