Track Operations 143
Section 12: Track Operations
Sport Insert: LL-2439
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A. The Quick Reference is located in Appendix D.
Reference Drawings:
Block Diagrams, A/S 3000 or 5000 Outdoor Sports............................................ Drawing A-124690
Insert; LL-2439 A/S 5000, Track ......................................................................... Drawing A-125094
Insert; LL-2441 A/S 5000, Team Name .............................................................. Drawing A-125290
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing located at the end of this section can be
used until a replacement can be ordered.
Use the label sheet provided with the console (Daktronics part # LL-2458) to attach the correct code
number label to the sport insert in the designated location. Write the code number in the space below.
If viewing a digital copy of this manual, print this page and fill in the code number.
Write the correct code number here:
Notes: The four-digit code displayed is the code that is currently selected. Code 8601 is the code for
manual data input.
External Timer Codes 8602 - 8604
 External timers must have specific Baud rates entered into the Venus ® 7000 computer when
using RTD information. The different rates are noted with each external timer.
 Code 8602 is for interfacing with the PowerTime timer. The Scoreboard typesetting in the
PowerTime under initialization/scoreboard/type must be set to multi-line and 1. The Baud
rate must be changed to 9600 in the Venus
® 7000 computer.
 Code 8603 is for interfacing with the OmniSport ® 1000 or OmniSport 6000. The “Current
Loop Scoreboard Setting” under Setup / Comm. Ports on the OmniSport 6000 must be set
to “SW-87/89, MS-167/169” if code 8603 is used with the OmniSport 6000 track timing
program. The baud rate must be set to 12800 Baud in the Venus
® 7000 computer.
 Code 8604 is for interfacing with Hawkeye or Finish Lynx timers.
The Baud rate for the Hawkeye and Finish Lynx timers must be set to 9600.
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
