Cricket Operations 235
Section 21: Cricket Operations
Sport Insert: 0G-319507 Cricket Code: 5598
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A.
Reference Drawings:
Insert; Cricket, A/S 5000 Series .......................................................................... Drawing A-319507
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
21.1 Cricket Competitor Status
Display Action
NN = batsman number
XX = batsman score
The score for batsman A and B is shown by the A- and
B- text, with the batsman number shown below them.
The total score for the team is shown by T- and wickets
and overs are shown by W- and OV-.
21.2 Cricket Keys
Wickets (+1,-1), Overs (+1,-1), Extras (+1,-1)
The , , and keys are used to increment their
respective totals. The –1 keys are used for correcting a wrong value.
Display Action
NN/NNN = current setting
Press , , or to
increment their respective totals.
The LCD shows which key was pressed and the new value.
The Extras +1, -1 keys will also increment and decrement
from the total score
When the key is pressed, it will transfer the
total score to the Last Wicket and also transfer the Batsman
score of the Batsman selected as facing to the Last Man.
Make sure the facing selection is set for the Batsman that is to
be out.
A-XX T- 0 B-XX
NN W-0 OV-40 NN
WI CKETS: +1
NN
OVERS: +1
NNN
EXTRA RUNS: +1
NN
