Volleyball Operations 153
Section 13: Volleyball Operations
Sport Insert: LL-2434
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A. The Quick Reference is located in Appendix D.
Reference Drawings:
Block Diagram: AS5000 BB- VB and WR #1 ...................................................... Drawing A-124686
Block Diagram: AS5000 BB- VB and WR #3 ...................................................... Drawing A-124688
Insert; LL-2434 A/S 5000, Volleyball ................................................................... Drawing A-125055
Insert; LL-2441 A/S 5000, Team Name .............................................................. Drawing A-125290
Block Diagram- A/S 3000 or 5000 BB- VB and WR #2 ....................................... Drawing A-125415
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
Use the label sheet provided with the console (Daktronics part # LL-2458) to attach the correct code
number label to the sport insert in the designated location. Write the code number in the space below.
If viewing a digital copy of this manual, print this page and fill in the code number.
Write the correct code number here:
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
13.1 Volleyball Keys
Time Out On/Off
stops and starts the time out clock. The length of both the full and
partial time outs can also be changed when the time out clock is stopped.
Note: Only the time outs configured in the EDIT SETTINGS function are displayed on
the LCD and available for selection.
Display Action
MM:SS = minutes, seconds
Press to display the configured time for
full time out length.
To start the full time out press .
To decline the selection of the full time out press .
TI ME OUTS-SELECT
FULL MM:SS
