Tae Kwon Do Operations 203
Section 17: Tae Kwon Do Operations
Sport Insert: 0G-96889 Red/White Code 283
0G-98375 White/Red Code 286
The Sport Insert drawing is located in Appendix B. The Block Diagram drawings are located in
Appendix A.
Reference Drawings:
Insert, Tae Kwon Do Code 283 ............................................................................. Drawing A-96889
Custom Insert, Tae Kwon Do Code 286 ............................................................... Drawing A-98375
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
17.1 Tae kwon do Keys
D
Display Action
N = current setting
Press to increment and < D -1> to decrement the
points value for the selected competitor.
Gamjeom (G)
Display Action
N = current setting
Press to increment and to decrement the
penalty count for the selected opponent.
Kyong-go (K)
Display Action
N = current setting
Press to increment and to decrement the ½
point deduction warnings for the selected opponent.
WHI TE D +1
N
WHI TE G +1
N
WHI TE K +1
N
