14 Basic Operation
Display Action
X = broadcast number
Y = channel number
Press to begin the radio channel test, or press the
down or up arrows to select another test.
This test shows the current Broadcast Group and Channel
number settings in the console. This test also sends a
command to the radio receiver in the scoreboard to show the
receiver’s settings on the first 2 clock digits* by alternating
between “bX” and “CY”, where X is the current Broadcast
Group and Y is the current Channel. Use this menu to verify the
console and scoreboard radio settings. Press any key to exit
the test.
X = firmware major number
Y = firmware minor number
Press to begin the server test, or press the down or
up arrows to select another test.
This test shows the console’s radio firmware version number.
This test also sends a command to the radio receiver in the
scoreboard to show the receiver’s firmware version number on
the first 2 clock digits* by alternating between “rX” and “_Y”,
where _ is a blank digit. For example, version 1.3 would display
as “r1” followed by ”_3”. Press any key to exit the test.
Press to exit the radio diagnostics menu and return
to the SELECT CODE prompt.
* Location of information displayed will vary on scoreboards without clocks.
RADI O TEST
-SERVER VER
RADI O TEST
-EXI T TEST ?
RADI O TEST
-RADI O CHAN
BCAST X CHAN Y
ANY KEY TO EXI T
SERVER VER X.Y
ANY KEY TO EXI T
