Wrestling Operations 173
Section 14: Wrestling Operations
Sport Insert: LL-2435
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A. The Quick Reference is located in Appendix D.
Reference Drawings:
Block Diagram: AS5000 BB- VB and WR #1 ...................................................... Drawing A-124686
Block Diagram: AS5000 BB- VB and WR #3 ...................................................... Drawing A-124688
Insert; LL-2435 A/S 5000, Wrestling ................................................................... Drawing A-124701
Insert; LL-2441 A/S 5000, Team Name .............................................................. Drawing A-125290
Block Diagram- A/S 3000 or 5000 BB- VB and WR #2 ....................................... Drawing A-125415
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
Use the label sheet provided with the console (Daktronics part # LL-2458) to attach the correct code
number label to the sport insert in the designated location. Write the code number in the space below.
If viewing a digital copy of this manual, print this page and fill in the code number.
Write the correct code number here:
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
14.1 Wrestling Keys
Match Number +1
Display Action
NNN = current setting
Press to increment the match number.
A prompt showing match number displays briefly.
NNN = weight class
If weight classes are selected, a prompt to select a weight
class will be shown on the LCD. Use the arrow keys to select
a weight class and press . The weight class
displays in the Match digits.
MATCH-+1 NNN
WEI GHT CLASS
01 NNN
