Soccer Operations 119
Section 10: Soccer Operations
Sport Insert: LL-2440
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A. The Quick Reference is located in Appendix D.
Reference Drawings:
Block Diagrams, A/S 3000 or 5000 Outdoor Sports............................................ Drawing A-124690
Insert; LL-2440 A/S 5000, Soccer ....................................................................... Drawing A-125215
Insert; LL-2441 A/S 5000, Team Name .............................................................. Drawing A-125290
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
Use the label sheet provided with the console (Daktronics part # LL-2458) to attach the correct code
number label to the sport insert in the designated location. Write the code number in the space below.
If viewing a digital copy of this manual, print this page and fill in the code number.
Write the correct code number here:
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
10.1 Game Clock
– Counting Up with Preset Stop Times
The following setup may be used to make the game clock count up and stop at preset times.
Display Action
After entering the correct sport code, start a new game and
press followed by <1> to count up.
First Half
Press twice. Using the number pad,
set the PERIOD time to “45:00”, and then press .
Press and the clock counts up from 0:00 to 45:00.
Second Half
Press twice. Using the number pad, set
the PERIOD time to “90:00”, and then press .
Press once. Using the number pad,
set the current time to “45:00”, and then press .
Press and the clock counts up from 45:00 to 90:00.
MAI N CLOCK- DOWN
1-UP 2-DOWN
MAI N CLOCK -EDI T
PERI OD 45:00 *
MAI N CLOCK -EDI T
PERI OD 90:00 *
MAI N CLOCK -SET
CURR 45:00 *
