10.4.- MODBUS TCP ( Bridge ) COMMUNICATIONS
general features
Maximum power of the module 2 W
Communications : Modbus TCP
Connector RJ-45
Protocol Modbus/TCP
Baud rate Ethernet 10BT / 100BT
Communications: RS-485 gateway
Bus RS-485
Protocol Modbus
Peripheral number 1 ... 255
Baud rate 9600 - 19200 - 38400 - 57600 - 76800 - 115200
Data bits 7- 8
Stop bits 1- 2
Parity No - even - odd
environmental features
Operating temperature -10ºC ... +50ºC
Storage temperature -20ºC ... +80ºC
Relative humidity (without condensation) 5 ... 95%
Maximum altitude 2000 m
Protection degree IP30
Mechanical features
Dimensions (mm) figure 215 and figure 216
Weight 80 g
enclosure V0 self-extinguishing plastic
Assembly Panel
Standards
Safety requirements for electrical equipment for measurement, control
and laboratory use
IEC 61010: 2010
electromagnetic compatibility (CeM)� Part 6-2: generic standards� Immu-
nity for industrial environments�
UNE-EN 6100-6-2:2006
electromagnetic compatibility (CeM)� Part 6-4: generic standards� emis-
sions standard for industrial environments�
UNE-EN 6100-6-4:2007
Coordination of the insulation of units installed in low voltage systems
(networks)
IEC 664: 2007
Information technology equipment� Radio disturbance characteristics�
Limits and methods of measurement�
UNE-EN 55022
