Creating and Starting a Test Case
Ethernet and Fibre Channel Application 65
Introducing the Test Setup
Nodes Available with
The Test node is the root of the test case. It allows the configuration
of the test application type, Interface Type, topology, and Clock
Mode. For RFC 2544, the selection of the sub tests and dual test set
are also available.
All tests
The Port node allows the selection and configuration of the physical
port and for 10Gig-E interface the selection of the transceiver mode
(LAN or WAN). For WAN transceiver mode, the WIS node will be
inserted in front of the Framing node.
All tests
The WIS node indicates that the WAN transceiver mode is selected.
Available with 10Gig-E interface only.
WAN transceiver
mode only
The Framing node allows the selection of the test framing layer. BERT test only
The Network node allows the selection of the network
Ethernet/Fibre Channel parameters for the port.
All test at the
exception of BERT
Unframed,
Framed Layer1
and Fibre Channel
The Remote Module node allows the selection of a remote
compatible module (FTB-8510B, FTB-8510G, FTB-8525/FTB-8535,
FTB-8120NGE/FTB-8130NGE, and RTU-310/RTU-310G).
EtherSAM and
RFC 2544 Dual
Test Sets tests
only
The Pattern node allows the selection of the pattern. BERT test only
