Pop-Up Windows
468 FTB-8500 Series and FTB-8120NGE/8130NGE
Data Capture Export
Data Capture Export
This pop-up window is only available from Traffic Analyzer - Capture tab.
Allows to export the data capture into a .pcap file format and to view the
file using Wireshark.

Save In: Allows to select the folder to save the capture file.
The capture file is saved in the following folder by default:
\data\My Documents\\Capture Data for FTB-200 and
\My Documents\\Capture Data for FTB-200 v2..

View File After Generation: Allows to display the report once it is
generated using the Wireshark application. Only available on the
FTB-200 v2. The View File After Generation check box is not selected
by default.

Generate & Save
Allows to generate and save the capture data. The name of the
captured file is automatically selected and contains the date and time
of the capture. Capture file bigger than 100Mbytes will be split into
multiple files.
Clicking on the Cancel button stops the capture generation. The
captured data already processed will be saved.
