Creating and Starting a Test Case
Ethernet and Fibre Channel Application 101
Ethernet TCP Throughput Test Case
Ethernet TCP Throughput Test Case
TCP Throughput (not available with Ethernet 10G interface): Allows
sending TCP/IP traffic to the network and provides an average of the TCP
Throughput based on the successfully transported bytes over the test time.
Two units running a TCP Throughput test are required. One unit will act as
the source (Local) and the other one as the destination (Remote).
Note: TCP Throughput software option needs to be enabled to be available.
Refer to Available Options on page 356.
To create a TCP Throughput test case, first create the test on the
remote module as follow:
1. Test configuration:
1a. Select
Ethernet 10/100/1000
as the Interface Type.
1b. Select Single Port as the
Topology. Topology is
only available with
FTB-8510B.
1c. Select TCP Throughput as the application type.
