Page 196: Configure
Traffic Analyzer Tabs
182
FTB-8500 Series and FTB-8120NGE/8130NGE
Traffic Filter Configuration
Traffic Filter Configuration
Allows gathering statistics according to the programmed filters. Up to 10
filters having up to four operands each can be defined and enabled.
Note: The Filter tab is only available when the Advanced Traffic Filtering
software option (SK-ADV-FILTERS) is enabled. Refer to Software Options
on page 355.
Press Main, Test, Traffic Analyzer, and Filters.
Filter Number (Filter No.)
Allows the selection of the filter number (1 to 10). The filter criteria, if
defined, will be displayed. A filter used (enabled) for data capture will not
be configurable and the message Filter in use for data capture is
displayed; refer to Filter on page 189.
Enable
Indicates that the selected filter is enabled or not.
Configure
See Filter Configuration on page 184 for more information.
Filter criteria
