Triggered frame details – EXFO FTB-8500 Series for FTB-200 User Manual
Page 481
Pop-Up Windows
Ethernet and Fibre Channel Application
467
Triggered Frame Details
Triggered Frame Details
This pop-up window is only available from Traffic Analyzer - Capture tab.
This pop-up indicates the details on the captured trigger frame. The
triggered frame corresponds to the first received frame that matches the
filter and the trigger settings (see Trigger on page 191).
Frame Number indicates the triggered frame position in the buffer.
The framing MAC/IP/UDP/TCP source and destination addresses are
displayed in a table.
