Report Generator
474 FTB-8500 Series and FTB-8120NGE/8130NGE
Transferring the Generated Test Report to the PC
Transferring the Generated Test Report to
the PC
Transfer the saved report to the PC
1. Local memory (FTB-200): If the report has been saved to the FTB-200
local folder, the report file need to be transferred to the PC using one of
the following methods:
1a. Network drive: Connect the FTB-200 and the PC to the network
and transfer the file to a network drive or directly on a shared
folder on the PC.
1b. USB connection (ActiveSync): Establish an ActiveSync
connection between the PC (USB host) and the FTB-200 (USB
client) using the supplied client/host USB cable. ActiveSync is
available on the supplied ToolBox CE CD; click Utilities and
Viewers and click Microsoft ActiveSync 4.1 to install it.
The default FTB-200 local folder is \Data\My Documents\folder\Report.
The following table lists the corresponding folder for each supported
model/application.
2. USB drive or Compact Flash: If the report has been saved on a
removable drive/media, plug the USB drive or the compact flash to the
PC.
3. Network drive: If the report has been saved on a network drive,
connect the PC to the network and retrieve the file from the network
drive.
Model Application Folder
FTB-8510B Packet Blazer PacketBlazerG2
FTB-8510G Packet Blazer PacketBlazer8510G
FTB-8525/FTB-8535 Packet Blazer FC PacketAnalyzer
FTB-8120NGE/ FTB-8130NGE Packet Analyzer PacketAnalyzer
