Path overhead, Path signal label (c2) – EXFO FTB-8500 Series for FTB-200 User Manual
Page 176
WIS Tabs
162
FTB-8500 Series and FTB-8120NGE/8130NGE
WIS OH RX
Path Overhead
J1
1
: Trace.
B3
1
: BIP-8
C2: Signal Label
G1: Status
F2: User Channel
H4
1
: Multiframe Indicator
Z3 and Z4: Growth
N1: Tandem Connection
Path Signal Label (C2)
The C2 byte is allocated to indicate the content of the STS SPE, including
the status of the mapped payloads. Refer to Path Signal Label (C2 byte) on
page 436 for more information.
1. Not supported in 10GigE standard..
