Pattern Tabs
246 FTB-8500 Series and FTB-8120NGE/8130NGE
Pattern TX
Pattern TX
Press Main, Test, Pattern, and Pattern TX.
Configuration

Test Pattern: Select the test pattern from the list.
Comment
Pattern Ethernet Fibre Channel a
a. Not available with FTB-8510G .
PRBS 2^9-1, PRBS 2^11-1,
PRBS 2^15-1, PRBS 2^20-1,
PRBS 2^23-1, PRBS 2^31-1
(default), User Pattern.
For more information about User Pattern, see User
Pattern on page 247.
CRPAT, CSPAT, CJTPAT Available with BERT
1000Mbps optical test
using Framed Layer 1.
Supported with Framed
Layer 1 when Latency
Tag is not selected, refer
to page 200.
Short CRTPAT, Long CRTPAT Not supported.
