Introducing the Smart User Interface
Ethernet and Fibre Channel Application 35
Main Window
Main Window
Test Setup and Tabs Display Area
The Test Setup window is displayed by default when the SUI is launched,
allowing the creation of the test case by travelling through the signal
structure. This area is also used to display the test configuration and result
tabs. Refer to Introducing the Test Setup on page 63 for more information
on Test Setup.
Application Name and Power Indicator
Displays the software application name and provides the battery and/or DC
power source indicator.
Application name and power
indicator
Main Menu
Print Screen
Exit
Help
Test controls
Global Test Status
Test Setup and tabs display area
