PATTERN SETTINGS
BGM Pattern Settings
11.2. BGM Pattern Settings
Clicking the [BGM] button on the pattern settings screen allows BGM patterns to be set.
(1)
(2)
(3)
(4)
(1) Number
Click on the box or press the arrow button to select the BGM pattern number.
1 to 16 (default: 1) Available Settings
(2) Name
Set the names of the BGM pattern.
(3) Input
Select the Audio Input Unit's input channel name set in "System Settings" (p. 51) .
This can be selected when the broadcast "Type" (p. 53) is set to "BGM."
None (default), Set input channel name Available Settings
(5)
Up to 32 alphanumeric characters. (default: BGM pattern 1 –16) Available Settings
(4) Zone ON/OFF buttons
Select the zones to use with the Input (3) above selected.
This allows the input name to be displayed in the box below the output zone
name.
Tip: For quick selection of multiple cells, refer to
p. 75 "Selecting multiple
cells."
Colored (selected), Colorless (not selected, default) Available Settings
[When selected]
