Rm-200sf – Toa SX-2000 Series User Manual
Page 113
113
EVENT SETTINGS
RM Event Settings (RM-200SF)
(2) Function
Select functions to be assigned to the keys of the RM-200SF and RM-210.
If the selected function needs particular settings, they are displayed on the "Contents."
None (default), Zone selection (Pattern), Zone selection (Individual),
Zone selection clear, BGM pattern change/end*, General broadcast*,
RM broadcast status, Lamp test
* Corresponding patterns must be created in advance to select these items.
• If the "Type" of the sound source registered in the System Manager of
is set to "General," the following functions can be selected.
General EV message start/end
• Following functions can be selected when the "Emergency broadcasting
function" has been set to "Used" in the "Basic Settings."
Emergency broadcast pattern start, Emergency broadcast pattern stop,
Emergency sequence stop, Emergency sequence phase shift,
Emergency reset
• Following functions can also be selected when the Surveillance function has
been set to "Used" in the "Basic Settings."
Failure output receipt, Failure output reset
Available Settings
(1)
(2)
(3)
(4)
12.7.1. RM-200SF
When the remote microphone selected from the "Name" pull-down menu is the RM-200SF, its setting screen
below is displayed.
RM-210 top
Function keys
1
10
FIREMAN'S MICROPHONE
RM-200SF
MIC
SP
CPU
OFF
ON
EMG
Emergency key
Function keys
RM-200SF top
SYS1
SYS2
SYS3
(1) Name
Enter the names of the keys of the RM-200SF and RM-210.
Up to 32 alphanumeric characters. (default: EMGKEY for the Emergency key,
SYSKEY 1 – 3 for the Function keys)
Available Settings
Note: Only the "Emergency broadcast pattern start" function can be assigned to the Emergency key
("EMGKEY").
