READING THE SETTINGS FILE
[Output zone pattern settings]
For the general broadcast patterns and RM zone selection patterns set using the old version Setting Software,
only their pattern names and output destination zones are converted as output zone patters on the new
Setting Software.
If there exist the patterns assigned different names and input sound sources but assigned the same output
destination using the old version Setting Software, their output zone pattern names are converted in the
following priory order: "General broadcast pattern" > "RM zone selection pattern" and "Smaller pattern No." >
"Larger patter No."
Pattern
General broadcast pattern 1
General broadcast pattern 2
General broadcast pattern 7
General broadcast pattern 8
General broadcast pattern 9
General broadcast pattern 10
General broadcast pattern 16
RM zone selection pattern 1
RM zone selection pattern 2
RM zone selection pattern 128
Pattern name
PAGE_PTN1
PAGE_PTN2
PAGE_PTN7
PAGE_PTN8
PAGE_PTN9
PAGE_PTN10
PAGE_PTN16
RM_PTN1
RM_PTN2
RM_PTN128
Output destination
Data conversion
Setting data set on the old version Setting Software
Setting data on the new version Setting Software
AO1-AO2 ZONE1
AO1-AO2 ZONE2
AO1-AO2 ZONE7
AO1-AO2 ZONE1-ZONE8
AO1-AO2 ZONE1
AO1-AO2 ZONE2
AO1-AO2 ZONE1-ZONE8
AO1-AO2 ZONE1-3-5-7
AO1-AO2 ZONE2-4-6-8
AO1-AO2 ZONE1-ZONE8
Sound source
AI1 CH5
AI1 CH5
AI1 CH5
AI1 CH5
AI1 CH6
AI1 CH6
AI1 CH6
Pattern
Output zone pattern 1
Output zone pattern 2
Output zone pattern 7
Output zone pattern 8
None
None
None
Output zone pattern 9
Output zone pattern 10
None
Pattern name
PAGE_PTN1
PAGE_PTN2
PAGE_PTN7
PAGE_PTN8
RM_PTN1
RM_PTN2
Output destination
AO1-AO2 ZONE1
AO1-AO2 ZONE2
AO1-AO2 ZONE7
AO1-AO2 ZONE1-ZONE8
AO1-AO2 ZONE1-3-5-7
AO1-AO2 ZONE2-4-6-8
If there exist the patterns
assigned different pattern
names and input sound
sources but assigned the
same output destination,
the new pattern(s) will be
created by avoiding
duplication of output zone
patterns.
In this example, as the
patterns' output
destinations in
red are
duplicated with those listed
above, these patterns will
not be converted into the
new Setting Software data
according to the said
conversion order rule.
Only the patterns of which output
destinations are not duplicated in the
general broadcast patterns and RM
zone selection patterns can be
reflected as output destination zone
patterns in the settings data on the
new Setting Software.
Their pattern names remain
unchanged.
[Event settings]
The following functions set in the "Control input settings" or "RM function key settings" using the old version of
the Setting Software are automatically converted.
Before conversion (s2d format) No. After conversion (smd format)
Volume change (UP, Pulse) Zone volume adjustment (Pulse)
Volume change (DOWN, Pulse) Zone volume adjustment (Pulse)
Volume change (UP, Level) None (Inconvertible)
Volume change (DOWN, Level)
(1)
(2)
(3)
(4) Zone volume attenuation (Level)
Note
Functions of (1), (2), and (4) at left may
become "None" after conversion
depending on amount of volume change
made before conversion.
