SYSTEM SETTINGS

SX-2000CO

(2) Control output

Enter each name of the control outputs of the SX-2000CO.

(3) Copy and Paste buttons

Pressing the [Copy] button copies all of the on-screen settings except the names preset by default.
Pressing the [Paste] button pastes the copied parameters in the same setting screen of other SX-2000CO
selected by Name (1).

Up to 32 alphanumeric characters. (Default name, for example, AO1-CO-1
represents the Control Output No. 1 of the SX-2000CO connected to the SX-
2000AO or SX-2100AO of Unit No. 1.)

Available Settings

(4) Back button

Returns to the previous screen.
