8.1.7. Mixing broadcast settings
Set whether or not to mix BGM output during EV message broadcasts.
The mixing status can be selected when "Type" is set to "General."
When "MIXING" is selected, the mixing setting ("MIXING" or "REDUCTION") for the SX-2000AI or SX-2100AI
takes effect for BGM play in all zones where the EV message is broadcast. (Refer to
p. 53, "SX-2000AI and
SX-2100AI Audio input details settings Module detail settings." )
Selecting "BGM CUT" cuts off BGM play in all zones where the EV message is broadcast, regardless of the
mixing settings of the SX-2000AI or SX-2100AI.
49
SYSTEM SETTINGS
SX-2000SM
Once (default), Endless Available Settings
MIXING (default), BGM CUT Available Settings
8.1.6. Playback method settings
Set the number of times that the EV message is repeated.
The number of times can be selected when "Type" is set to "General."
