SYSTEM SETTINGS
SX-2000CI
(3) Copy and Paste buttons
Pressing the [Copy] button copies all of the on-screen settings except the names preset by default.
Pressing the [Paste] button pastes the copied parameters in the same setting screen of other SX-2000CI
selected by Name (1).
(4) Back button
Returns to the previous screen.
(2) Control input
Enter each name of the control inputs of the SX-2000CI.
Up to 32 alphanumeric characters. (Default name, for example, AO1-CI-1
represents the Control Input No. 1 of the SX-2000CI connected to the SX-2000AO
or SX-2100AO of Unit No. 1.)
Available Settings
(1) Name
Click on the box, or press the right or left arrow button to select the target SX-2000CI.
Default name, for example, AO1-CI1 represents the SX-2000CI of Unit No. 1 connected to the SX-2000AO
or SX-2100AO of Unit No.1.
(1)
(2)
(3)
(4)
