102
[ If "BGM pattern change/end" is selected for "Function" ]
(3) Contents (left side)
Select the BGM broadcast pattern to be activated by the control input.
Set the broadcast pattern using
"Pattern settings BGM pattern settings" (p. 78) .
If the broadcast pattern is set to "End," then it is not possible to set "Control output pattern" (next item).
End (default), Set BGM broadcast pattern Available Settings
(4) Contents (right side)
Select the control output pattern that operates in synchronization with the control input.
Set the control output pattern using
"Pattern settings Control output pattern settings" (p. 81) .
None (default), Set control output pattern Available Settings
EVENT SETTINGS
SM Event Settings
[ If "General broadcast (Level)" is selected for "Function" ]
(3) Contents (left side)
Select the general broadcast pattern to be activated by the control input.
Set the broadcast pattern using
"Pattern settings General broadcast pattern settings" (p. 79) .
Setting the broadcast pattern to "None" and "Control output pattern" (next item) permits only the control
output to be operated in synchronization with the control input.
None (default), Set general broadcast pattern Available Settings
(4) Contents (right side)
Select the control output pattern that operates in synchronization with the control input.
Set the control output pattern using
"Pattern settings Control output pattern settings" (p. 81) .
None (default), Set control output pattern Available Settings
[ If "General broadcast (Pulse)" is selected for "Function" ]
(3) Contents (left side)
Select the general broadcast pattern to be activated by the control input.
Set the broadcast pattern using
"Pattern settings General broadcast pattern settings" (p. 79) .
Setting the broadcast pattern to "None" and "Control output pattern" (next item) permits only the control
output to be operated in synchronization with the control input.
None (default), Set general broadcast pattern Available Settings
(4) Contents (right side)
Select the control output pattern that operates in synchronization with the control input.
Set the control output pattern using
"Pattern settings Control output pattern settings" (p. 81) .
None (default), Set control output pattern Available Settings
