PATTERN SETTINGS
Output Zone Pattern Settings
11.1. Output Zone Pattern Settings
Clicking the [Output zone] button on the pattern settings screen allows output zone patterns to be set.
By allocating set output zone patterns to various broadcast patterns, broadcasts (General-purpose broadcast,
and Emergency broadcast) can be made to any desired zones.
(1)
(2)
(3)
(1) Number
Click on the box or press the arrow button to select the output zone pattern number.
1 to 128 (default: 1) Available Settings
(4)
(2) Name
Enter the name of the output zone pattern.
(3) Zone ON/OFF buttons
Click the buttons corresponding to the zones to use.
Tip: For quick selection of multiple cells, refer to
p. 75 "Selecting multiple cells."
Colored (selected), Colorless (not selected, default) Available Settings
[When selected]
(4) Copy and Paste buttons
Pressing the [Copy] button copies all of the on-screen settings except the name preset by default.
Pressing the [Paste] button pastes the copied parameters in the same setting screen of other output zone
pattern selected by Number (1).
Up to 32 alphanumeric characters. (default: Zone pattern 1 – 128) Available Settings
