Chapter 8 RS-232C I/O
93
8
Transmitted data for each display is as follows:
Example
Control Command 1
Command list II
1. Upper line: Character code, Lower line: ASCII code
Note 1: "#" is a character code between 0 and 4, or the ASCII code corresponding
to the character code.
0: Outputs data from all output numbers.
1 to 4: Outputs data from the specified output number (OUT1 to OUT4).
Note 2: When the LS-5000 series receives the ASCII (character) code given in
code list II, it performs the specified operation.
Function Command received 1. Description
Timing [T] [#] [CR] Turns ON the synchronous input
54H#0DH
[U] [#] [CR] Turns OFF the synchronous input
55H#0DH
Reset [Q] [#] [CR] Reset input
51H#0DH
Auto-zero [V] [#] [CR] Auto-zero input
56H#0DH
[W] [#] [CR] Resets the auto-zero input
57H#0DH
Display status Normal mode Pitch mode
OUT1 123.45670 Max.: 999.99995
Min.: -99.99995
OUT2 -99.99995 Max.: - - -.- - - - -
Min.: - - -.- - - - -
OUT3 - - -.- - - - - Max.: - - -.- - - - - (No setting)
Min.: - - -.- - - - - (No setting)
OUT4 999.99995 Max.: 0.00005
Min.: -0.00005
Received command Transmitted data
[M] [1] [CR] 123.45670 999.99995
-99.99995
[M] [0] [CR] 123.45670 (OUT1) 999.99995 (OUT1 Max.)
-99.99995 (OUT2) -99.99995 (OUT1 Min.)
- - -.- - - - - (OUT3) - - -.- - - - - (OUT2 Max.)
999.9995 (OUT4) - - -.- - - - - (OUT2 Min.)
- - -.- - - - - (OUT3 Max.)
- - -.- - - - - (OUT3 Min.)
0.00005 (OUT4 Max.)
-0.00005 (OUT4 Min.)
