Chapter 8 RS-232C I/O

■ Operating Procedure
Example: Turn ON the synchronous input.

Note 1: The operating procedure for functions other than “synchronous input: ON”
is similar to the above.

Note 2: The timing, reset and auto-zero terminal input, and the RS-232C command
input can be simultaneously used.

Control Command 2

Command list III

1. Upper line: Character code, Lower line: ASCII code

Note 1: # is a character code between 1 and 16, or the ASCII code corresponding
to the character code.

1 to 16: The program number can be changed to a number between 1 and 16.

Note 2: When the LS-5000 series receives the ASCII (character) code given in
code list III, it performs the specified operation.

LS-5000 series

During

measurement

During

measurement

Synchronous input for

OUT1 is turned ON

Personal computer

Sends [T] [1] [CR]

End

Function

Command received

Description

Program No.

[P] [#] [#] [CR]

Program number is changed

Selection

50H##0DH
