KEYENCE LS-5000 User Manual
Page 95
Chapter 8 RS-232C I/O
89
8
■ Examples of Connections
•
Connection with a personal computer
Delimiter: CR
•
Connection with the KV series
*
KV-300 series is not available in European area.
OP-26401 + OP-96368
(D-sub 9-pin connector + cable)
Personal computer
Straight cable
KV-10/16/24/40/80
KV-300 Series*
Cross cable OP-96607
Straight cable
OP-96368 (cable) + OP96369
(D-sub 25-pin connector)
AC
power supply
KV-U4
CPU
KV-300
Serial Interface
module KV-L2
Data format (Delimiter: STX + ETX)
The displayed value is output continuously.
