Measurement Range and Accuracy
■ LS-5041
200 mm
40
80
80 120
± 8 µm
± 10 µm
± 20 µm
Transmitter
Receiver
■ LS-5121
Temperature Characteristics (Typical)
■ LS-5041
■ LS-5121
Ambient temperature
0°C (32°F) 10°C (50°F) 20°C (68°F) 30°C (86°F) 40°C (104°F) 50°C (122°F)
Temperature fluctuation
+1.4
+0.6
0
-0.6
-1.6
-2.7
When a 10 mm diameter rod with is measured in the middle of the measuring range. [Reference temperature: 20°C
(68°F)]
Unit: µm
Ambient temperature
0°C (32°F) 10°C (50°F) 20°C (68°F) 30°C (86°F) 40°C (104°F) 50°C (122°F)
Temperature fluctuation
+10.0
+5.0
0
-5.0
-10.0
-15.0
When a 40 mm diameter rod with is measured in the middle of the measuring range. [Reference temperature: 20°C
(68°F)]
Unit: µm
80 mm
20
10
20
30
30 40
± 2 µm
± 4 µm
± 8 µm
Transmitter
Receiver
